EasyStand Evolv XT – Extra Tall Modular Sit-to-Stand Stander
The EasyStand Evolv XT is designed for larger users, offering the same industry-leading modularity of the Evolv series with dimensions tailored for individuals up to 6’10” tall. With over 60 available positioning and support components, the Evolv XT can be configured to meet a wide range of needs — from minimal support to full postural control — without costly custom modifications.
Positioning
The Evolv XT’s pivot points align with the body’s natural movement, reducing shear and ensuring supports like hip guides, lateral supports, and headrests remain properly positioned during transitions. Adjustable footplates and optional independent knee pads accommodate hip and knee contractures while promoting optimal alignment and comfort.
Accessibility & Independence
Its open base allows easier independent transfers, and optional features like the Transfer Seat, Rotating Seat, Swing-Away Front, or Removable Back make assisted transfers more manageable. The Evolv XT can be operated with the standard manual hydraulic actuator or upgraded to the push-button Pow’r Up Lift for effortless standing.
Safety & Convenience
The Evolv XT supports a safe, three-step process to standing — adjust, transfer, and stand. Its stable footprint and ergonomic adjustability give both caregivers and users confidence, while optional trays enhance activity in seated, partial stand, or full stand positions.
Base Unit Specifications
| Approximate Height Range | 6’0″–6’10″ (183–208 cm) |
|---|---|
| Weight Limit | 350 lbs (159 kg) |
| Maximum Mass (fully loaded) | 170 lbs (77 kg) |
| Seat Depth Range (from seat pivot) | 20″–25″ (51–64 cm) |
| Seat to Footplate Range (from seat pivot) | 17″–23″ (43–58 cm) |
| Kneepad Depth Range (from seat pivot) | 4.75″–7″ (12–18 cm) |
| Seat Height | 23.5″ (60 cm) |
| Seat Dimensions | 19″ W × 21.5″ L (48 × 54 cm) |
| Standard Tray Size | 21″ × 24″ (53 × 61 cm) |
| Tray/Chest Pad Depth Range (from seat pivot) | 0″–10.5″ (0–27 cm) |
| Standard Tray Height Range (from seat pivot) | 15.5″–30.5″ (39–77 cm) |
| Footprint (at widest points) | 29.5″ × 37.5″ (70 × 95 cm) |
| Weight of Basic Unit | 112 lbs (51 kg) |
| Frame Color | Charcoal |
| Upholstery Color | Black |
| Locking Caster Diameter | 5″ (13 cm) |
| Footplates – Plantar | 10° in 3 increments (not Glider) |
| Footplates – Dorsi | 10° in 3 increments (not Glider) |
| Footplates – Toe-out | 15° in 3 increments (not Glider) |
Shadow Tray Specifications
| Shadow Tray Height from Seat | 12.25″ (31 cm) – acrylic tray is 1″ shorter |
|---|---|
| Shadow Tray Size | 21″ × 24″ (53 × 61 cm) |
| Weight of Evolv with Shadow Tray | 115 lbs (52 kg) |
Mobile Option Specifications
| Weight of Mobile Option | 38 lbs (17 kg) |
|---|---|
| Total Weight of Evolv Mobile | 135 lbs (61 kg) |
| Footprint (with pushrims) | 28.5″ × 36″ (72 × 91 cm) |
| Wheelbase | 29.75″ (76 cm) |
| Pushrim Height (from floor) | 45″ (114 cm) |
| Wheel Locks | 1/4 turn rotation to lock/unlock |
| Drive Chain Tensioning Method | Self-tensioning gravity operated |
| Mobile Tray Size | 18″ W × 19″ L (46 × 48 cm) |
Warranty
Includes a limited manufacturer warranty covering defects in materials and workmanship. Refer to official documentation for complete warranty terms and coverage.
